Small AC Vertical Flange Type Gear Motor
Small AC Vertical Flange Type Gear Motor (6w、15w、25w、40w、60w、90w)
Gear Box Ratio 3~180
Brake、speed controller、Terminal Box are Optional.
Made in Taiwan
Gear Box Ratio 3~180
Brake、speed controller、Terminal Box are Optional.
Made in Taiwan
| Input Voltage | AC |
|---|---|
| Phases | 1、3 |
| Output Power (Wattage) | 6w、15w、25w、40w、60w、90w |
| Number of Poles | 2P、4P |
| Rated Voltage (V) | Single Phase110V、220V，Single or Three Phase220V，Three Phase220V、380V |
| Frequency of Use | 50hz/60hz |
| Rated Current | Depending on Type |
|---|---|
| Rated Speed | 1450 RPM / 1750 RPM |
| Insulation Class | E、F |
| Protection Class | IP44、IP54 |
| Installation Method | Flange Type |
| Appearance/Design | 60mm、70mm、80mm、90mm |
Please Contact us for more infomation to chose the type you need.
