AC Horizontal Foot Type Gear Motor
NL05
Advantages of AC Gear Motors Made In Taiwan.


High Efficiency & Reliability


Compact & Space-Saving Design


High Torque Output


Smooth & Quiet Operation


Energy Saving


Durability & Long Lifespan


Wide Range of Applications
Input Voltage AC
Phases 1、3
Output Power (Wattage) 100W-200W-400W-750W-1500W-2200W-3700W
Horsepower 1/8HP-1/4HP-1/2HP-1HP-2HP-3HP-5HP
Number of Poles 4
Rated Voltage (V) 200V/220V/230V/240V/380/400V/440/460V/480V
Frequency of Use 50hz/60hz
Rated Current Depending on Type
Rated Speed 1450 RPM / 1750 RPM
Insulation Class E、F
Protection Class IP44、IP54
Installation Method Horizontal type、Flange
Appearance/Design Aluminum、Cast iron
Certifications CE、UL、RoHS、CSA

Advantages of AC Gear Motors Made In Taiwan.

  1. High Efficiency & Reliability
    AC gear motors provide consistent and efficient performance, ensuring reliable operation with minimal maintenance.

  2. Compact & Space-Saving Design
    The integrated gear mechanism allows for a more compact structure, making it ideal for applications with space constraints.

  3. High Torque Output
    The built-in reduction gear increases torque, making it suitable for heavy-load applications while maintaining stable operation.

  4. Smooth & Quiet Operation
    Designed with precision engineering, AC gear motors reduce noise and vibration, providing a smoother and quieter performance.

  5. Energy Saving
    With high efficiency and low power consumption, AC gear motors contribute to energy savings and reduced operational costs.

  6. Durability & Long Lifespan
    Built with high-quality materials and robust construction, these motors ensure long-lasting performance even in demanding environments.

  7. Wide Range of Applications
    AC gear motors are widely used in automation, conveyor systems, medical equipment, packaging machinery, and more.
